Frequency Range 140MHz - 174MHz (2m Band)
Remark: Rod antennas can be adapted to frequencies up up to 450MHz by shortening the rod.
KFA 146 ES / FS with rod 540mm
KFA 148 FS / EK with glass fiber rod with spring 1315mm
KFA 149 ES / EK with steel rod 1315mm
KFA 146 ES 15 176 210 014
Aerial rod: Stainless steel
Length after tuning: 540mm (equal to λ/4)
Gain: 0dB (referred to λ/4 rod, mid of roof)
VSWR: < 2:1 (Δf 10MHz)
Maximum power: 50W
Impedance: 50Ω
Cable: Optional
KFA 146 FS 15 186 210 014
Aerial rod: Stainless steel, with spring
Length after tuning: 540mm (equal to λ/4)
Gain: 0dB (referred to λ/4 rod, mid of roof)
VSWR: < 2:1 (Δf 10MHz)
Maximum power: 50W
Impedance: 50Ω
Cable: Optional
KFA 149 ES 15 176 220 213
Antenna rod: Stainless steel
Length after tuning: 1400mm (equal to 5/8 λ)
Gain: 2dB (referred to λ/4 rod, mid of roof)
VSWR: < 1,5:1 (Δf 4MHz)
Maximum power: 30W
Impedance: 50Ω
Cable: Option
KFA 148 FS 15 156 220 216
Aerial rod: Glass fiber with spring
Length after tuning: 1315mm (equal to 5/8 λ)
Gain: 2dB (referred to λ/4 rod, mid of roof)
VSWR: < 1,5:1 (Δf 4MHz)
Maximum power: 30W
Impedance: 50Ω
Cable: Option
